2.0mm pitch Three Row 2-50Pins Female Header Connector Board To Board PCB connector
Custom Headers provide design flexibility, production efficiency while decreasing needed equipment assets.with Horizontal, right-angle and vertical about orientation & single and dual Rows.
Specifications
1. Pitch:2.54mm
2. Connector Name: PCB Connector/Female Header
3. Insulation Material:PA9T UL 94-V0
4. Contact Material: Copper Alloy
5: Mounting Type: Through Hole
6: Number of Row: Single
7: Contact Finish: Gold Over Nickel
8: Termination: Solder
9: Color:Black
10: Current Rating:2.0A
11: Withstand Voltage:500V AC/DC
12: Contact Resistance:20mΩ Max
13: Pin Length: Customization
14: Pin Available:2Pins to 40Pins
15. Number of Row:Three Rows
16. Fastening Type:Push-Pull
17. Style:Board to Board
18. Contact Type:Female Socket
19. Platic Height: 6.35mm+-0.15
Environmental
1. Storage Temperature -40°C~105°C Relative Humidity <80%.
2. Opration Temperature -40°C~+105°C
Lead-free process,compliant RoHS.
Our Quality
Except the plating , From Design tooling , stamping , Injection molding , assemble , Testing , packing .All the step are doing by ourself . So we can control the quality.
Service
good pre-sales & after-sales service &Strong technical support
1. New Project: Strong technical and ideal support your new design
2. Existing projects: Try to help customer to save the cost to offer the good quality product and save time.
3. Free Samples:3-5 PCS of each part number.
4. Customer complaint:24-48 hours reply 8D report.
5. Warranty : 24 months ( Merchandise are promised to be promptly returned, replacement,or repair kits if
customers are not satisfied)
